risc::StaticPathInstanceMapper Class Reference

#include <static_path_instance_mapper.h>

Inheritance diagram for risc::StaticPathInstanceMapper:

Collaboration diagram for risc::StaticPathInstanceMapper:

Public Types
typedef std::pair < InstanceTree, int >	PathWithID

Public Member Functions
	StaticPathInstanceMapper (InstanceTree root)
	This is the default constructor and need a design and a segment graph. The lookup table will be automatically created. More...
void	determine_lookup_table (InstanceTree root)
	This function traverses the design and pushes all modules and hierarchical channel instances into the path_to_id_mapping_ lookup table. The traversing is dependent on the declaration order of the member variables. Also, it follows depth first search. CAUTION: The function Design::reset_instance_counter() must be used first! Otherwise wrong intance id's a generated! More...
virtual int	get_id (InstanceTree tree)
	This function returns for a given tree the corresponding instance id. More...
InstanceTree	get_instance_tree (int id, std::list< InstanceTree > potential_instances)
	This function returns for a given id and potential mapping candidates the corresponding instance tree. More...
virtual bool	perform_dynamic_analysis ()
	This functions returns true if the path instance mapper should perform a dynamic analysis. More...
void	print_mapping ()
	The function prints the lookup table in the terminal. More...
virtual DynamicModule *	get_dynamic_tree_root ()
	This function returns the root node of the dynamic analysis CAUTION: This function is only for the DynamicPathInstanceMapper. More...
virtual int *	get_global_variable_address (std::string variable_name)
	This functions returns the address of the global variable with the name 'variable_name' CAUTION: This function is only for the DynamicPathInstanceMapper. More...
virtual std::string	get_global_variable_name (int *variable_address)
	This functions translates the address of a global variable into the associated variable name CAUTION: This function is only for the DynamicPathInstanceMapper. More...

Public Attributes
std::vector< PathWithID >	path_to_id_mapping_
	This is the lookup table from path to instance id. More...
int	max_instances_
	This variable counts what is the max of instances. More...

Member Typedef Documentation

typedef std::pair<InstanceTree, int> risc::PathInstanceMapper::PathWithID

inherited

Constructor & Destructor Documentation

risc::StaticPathInstanceMapper::StaticPathInstanceMapper

(

InstanceTree

root

)

This is the default constructor and need a design and a segment graph. The lookup table will be automatically created.

Member Function Documentation

risc::StaticPathInstanceMapper::determine_lookup_table

(

InstanceTree

root

)

This function traverses the design and pushes all modules and hierarchical channel instances into the path_to_id_mapping_ lookup table. The traversing is dependent on the declaration order of the member variables. Also, it follows depth first search. CAUTION: The function Design::reset_instance_counter() must be used first! Otherwise wrong intance id's a generated!

risc::PathInstanceMapper::get_dynamic_tree_root ( )

virtualinherited

This function returns the root node of the dynamic analysis CAUTION: This function is only for the DynamicPathInstanceMapper.

Reimplemented in risc::DynamicPathInstanceMapper.

risc::PathInstanceMapper::get_global_variable_address ( std::string  variable_name )

virtualinherited

This functions returns the address of the global variable with the name 'variable_name' CAUTION: This function is only for the DynamicPathInstanceMapper.

Reimplemented in risc::DynamicPathInstanceMapper.

risc::PathInstanceMapper::get_global_variable_name ( int *  variable_address )

virtualinherited

This functions translates the address of a global variable into the associated variable name CAUTION: This function is only for the DynamicPathInstanceMapper.

Reimplemented in risc::DynamicPathInstanceMapper.

risc::StaticPathInstanceMapper::get_id ( InstanceTree  tree )

virtual

This function returns for a given tree the corresponding instance id.

Reimplemented from risc::PathInstanceMapper.

risc::StaticPathInstanceMapper::get_instance_tree ( int  id, std::list< InstanceTree >  potential_instances  )

virtual

This function returns for a given id and potential mapping candidates the corresponding instance tree.

Reimplemented from risc::PathInstanceMapper.

risc::StaticPathInstanceMapper::perform_dynamic_analysis ( )

virtual

This functions returns true if the path instance mapper should perform a dynamic analysis.

Implements risc::PathInstanceMapper.

risc::PathInstanceMapper::print_mapping ( )

inherited

The function prints the lookup table in the terminal.

Member Data Documentation

int risc::PathInstanceMapper::max_instances_

inherited

This variable counts what is the max of instances.

std::vector<PathWithID> risc::PathInstanceMapper::path_to_id_mapping_

inherited

This is the lookup table from path to instance id.

---

The documentation for this class was generated from the following files:

• /local/lecs/lecs/risc_v0.6.2/sources/build/risc_v0.6.2/src/internal_representation/static_path_instance_mapper.h
• /local/lecs/lecs/risc_v0.6.2/sources/build/risc_v0.6.2/src/internal_representation/static_path_instance_mapper.cpp
