sc_core::sc_semaphore Class Reference
The sc_semaphore primitive channel class. More...
#include <sysc/communication/sc_semaphore.h>
Public Member Functions | |
| sc_semaphore (int init_value_) | |
| sc_semaphore (const char *name_, int init_value_) | |
| virtual int | wait (int) |
| A new parameter segment ID is added for the out-of-order simulation. | |
| virtual int | trywait () |
| virtual int | post () |
| virtual int | get_value () const |
| virtual const char * | kind () const |
Protected Member Functions | |
| bool | in_use () const |
| void | report_error (const char *id, const char *add_msg=0) const |
Protected Attributes | |
| sc_event | m_free |
| int | m_value |
| CHNL_MTX_TYPE_ | m_mutex |
| A lock to protect concurrent communication through sc_semaphore. | |
Detailed Description
The sc_semaphore primitive channel class.
Definition at line 46 of file sc_semaphore.h.
Constructor & Destructor Documentation
| sc_core::sc_semaphore::sc_semaphore | ( | int | init_value_ | ) | [explicit] |
| sc_core::sc_semaphore::sc_semaphore | ( | const char * | name_, | |
| int | init_value_ | |||
| ) |
Member Function Documentation
| virtual int sc_core::sc_semaphore::get_value | ( | ) | const [inline, virtual] |
Implements sc_core::sc_semaphore_if.
Definition at line 76 of file sc_semaphore.h.
| bool sc_core::sc_semaphore::in_use | ( | ) | const [inline, protected] |
Definition at line 92 of file sc_semaphore.h.
| virtual const char* sc_core::sc_semaphore::kind | ( | ) | const [inline, virtual] |
Reimplemented from sc_core::sc_object.
Definition at line 85 of file sc_semaphore.h.
| virtual int sc_core::sc_semaphore::post | ( | ) | [virtual] |
Implements sc_core::sc_semaphore_if.
| void sc_core::sc_semaphore::report_error | ( | const char * | id, | |
| const char * | add_msg = 0 | |||
| ) | const [protected] |
| virtual int sc_core::sc_semaphore::trywait | ( | ) | [virtual] |
Implements sc_core::sc_semaphore_if.
| virtual int sc_core::sc_semaphore::wait | ( | int | ) | [virtual] |
A new parameter segment ID is added for the out-of-order simulation.
Implements sc_core::sc_semaphore_if.
Member Data Documentation
sc_event sc_core::sc_semaphore::m_free [protected] |
Definition at line 101 of file sc_semaphore.h.
CHNL_MTX_TYPE_ sc_core::sc_semaphore::m_mutex [mutable, protected] |
A lock to protect concurrent communication through sc_semaphore.
Definition at line 108 of file sc_semaphore.h.
int sc_core::sc_semaphore::m_value [protected] |
Definition at line 102 of file sc_semaphore.h.
The documentation for this class was generated from the following file:
- sysc/communication/sc_semaphore.h
