EECS 31/CSE 31/ICS 151 Homework 7

View Questions Only

Problem

Question

Design a Polite & Stupid Elevator

Assumptions:

  1. There are three floors
  2. Door opens on every floor
  3. One button at any time

Solution

  1. We assume there are 5 states as shown below. The inputs to the state diagram are the Button 1, 2, 3 or no button pressed. F1, F2 and F3 represent the elevator's destination is 1, 2, 3 floor. F2D represent the elevator passing floor 2 when it goes down from third floor to first floor without pressing Button 2. F2U represent the elevator passing floor 2 when it goes up from first floor to third floor without pressing Button 2. The outputs of this state diagram are directions of the elevator, which indicating the elevator is going up or going down.
    State Diagram
  2. Based on the above state diagram, we can get the next-state table on different button inputs:
    Present State Next State
    Button 1 Button 2 Button 3 No Button
    F1 F1 F2 F2U F1
    F2 F1 F2 F3 F2
    F2U F3 F3 F3 F3
    F2D F1 F1 F1 F1
    F3 F2D F2 F3 F3
    We encode these 5 states with F1 = 010, F2 = 100, F2U = 001, F2D = 000, F3 = 110. Then we can represent these 5 states by using three D flip-flops. Let Q2, Q1,and Q0 represent the outputs of these D flip-flops. For the input button, we use B1, B0 to represent which button is pressed. Hence, the above table can be transformed to:
    Present State Next State
    Button 1 Button 2 Button 3 No Button
    Q2Q1Q0 B1B0 = 01 B1B0 = 10 B1B0 = 11 B1B0 = 00
    F1 = 010 F1 = 010 F2 = 100 F2U = 001 F1 = 010
    F2 = 100 F1 = 010 F2 = 100 F3 = 110 F2 = 100
    F2U = 001 F3 = 110 F3 = 110 F3 = 110 F3 = 110
    F2D = 000 F1 = 010 F1 = 010 F1 = 010 F1 = 010
    F3 = 110 F2D = 000 F2 = 100 F3 = 110 F3 = 110
  3. We can draw the K-maps for the next-state table as following. There are 5 variables, the output of the 3 D flip-flops Q2, Q1 and Q0 and the input button B1, B0. Each value in a square represent the next-state value corresponding to the next-state table. For those square not defined in the next-state table, we use an 'X' to indicating a "don't care" occasion.
    K-Map
    Replacing F1, F2, F3, F2U and F2D with the values of Q2, Q1 and Q0, we can get 3 K-Maps for Q2(next), Q1(next) and Q0(next), as shown below:
    3 K-Maps
    Q2(next) = Q0 + Q2B1 + Q2B0' + Q1B1B0'
    Q1(next) = Q2'Q1' + Q2'B1' + Q1B1'B0' + Q2B1B0 + Q2Q1'B0
    Q0(next) = Q2'Q1B1B0
  4. Similarly, we can get the output equations based on the following K-Maps:
    2 K-Maps
    Down = Q2'Q1'Q0' + Q2B1'B0 + Q2Q1B1B0'
    Up = Q0 + Q2'Q1B1 + Q2Q1'B1B0
  5. Finally, we can draw the schematic based on the next-state and output equations:
    Schematic
